Rack-be építhető tápegységek

R 12V/16x1,5A/PTC(W=19”, H=2U, Power supply output: 16 x 0,87A/12VDC (ΣI=14A max), Fuse type: PTC – 16x1,5A, Voltage adjustment range: 12V÷15V, Effici

R 12V/16x1,5A/TOPIC(W=19”, H=2U, Power supply output: 16 x 0,87A/12VDC (ΣI=14A max), Fuse type: standard fuses – 16x1,5A, Voltage adjustment range: 12

R 12V/8x1,5A/PTC(W=19”, H=2U, Power supply output: 8 x 1A/12VDC (ΣI=8A max), Fuse type: PTC – 8x1,5A, Voltage adjustment range: 12V÷15V, Efficiency: 8

R 12V/8x1,5A/TOPIC(W=19”, H=2U, Power supply output: 8 x 1A/12VDC (ΣI=8A max), Fuse type: standard fuses – 8x1,5A, Voltage adjustment range: 12V÷15V,

RAC 24VAC/8x1A/PTC(W=19”, H=2U, Power supply output: 8 x 1A/24VAC - with galvanic separation of each channel, Fuse type: PTC – 8x1A)

RAC 24VAC/8x1A/TOPIC(W=19”, H=2U, Power supply output: 8 x 1A/24VAC - with galvanic separation of each channel, Fuse type: standard fuses – 8x1A)

ROUPS 12V/5A(W=19”, H=2U, Power supply output: 1 x 5A/12VDC, Fuse type: TOPIC – 1x5A, Battery charging current: 1A, Efficiency: 71%)

RP 48V/16x0,5A(W=19”, H=2U, Power supply output: 16 x 0,3A/48VDC (15,4W/ channel) – RJ45, Fuse type: PTC – 8x0,5A, Efficiency: 86%)

RP 48V/8x0.5A(W=19”, H=2U, Power supply output: 8 x 0,3A/48VDC (15,4W/ channel) – RJ45, Fuse type: PTC – 8x0,5A, Efficiency: 82%)

RPUPS 54V/12V/5A(W=19”, H=2U, Power supply output: 12x0,3A/54VDC + 1x4A/12VDC (RJ45- cameras IP + power supply: for recorder), Fuse type: PTC – 12x0,5

RUPS 13,8V/8x1A/PTC(W=19”, H=2U, Power supply output: 8 x 1A/13,8VDC, Fuse type: PTC – 8x1,0A, Battery charging current: 1,0A, Efficiency: 85%)

RUPS 13,8V/8x1A/TOPIC(W=19”, H=2U, Power supply output: 8 x 1A/13,8VDC, Fuse type: standard fuses – 8x1,0A, Battery charging current: 1,0A, Efficiency

RUPS 27,6V/8x1A/PTC(W=19”, H=2U, Power supply output: 8 x 1A/27,6VDC, Fuse type: PTC – 8x1,0A, Battery charging current: 1,0A, Efficiency: 85%)

RUPS 27,6V/8x1A/TOPIC(W=19”, H=2U, Power supply output: 8 x 1A/27,6VDC, Fuse type: standard fuses – 8x1,0A, Battery charging current: 1,0A, Efficiency

RUPS 54V/8x0,5A/PTC(W=19”, H=2U, Power supply output: 8 x 0,5A/27,6VDC, Fuse type: PTC – 8x0,5A, Battery charging current: 0,5A, Efficiency: 85%)

RUPS 54V/8x0,5A/TOPIC(W=19”, H=2U, Power supply output: 8 x 0,5A/27,6VDC, Fuse type: standard fuses – 8x0,5A, Battery charging current: 0,5A, Efficien
